MikroTik CSS318-16G-2S+IN 16-Port Gigabit Managed Switch with 2x 10G SFP+ Uplinks (SwOS)

MikroTik CSS318-16G-2S+IN — 16-Port Gigabit Managed Switch with 2x 10G SFP+ Uplinks for ISP & Enterprise Networks

The MikroTik CSS318-16G-2S+IN is a compact, high-performance 16-Port Gigabit Managed Switch with 2x 10G SFP+ uplink ports, purpose-built for ISPs, WISPs, and enterprise networks across Uganda and East Africa. Running MikroTik SwOS, this switch delivers Layer 2 managed switching — including VLAN, RSTP, bandwidth limiting, and port mirroring — through a clean, browser-based interface that requires no CLI expertise.

Engineered in MikroTik's signature white 1U rackmount chassis, the CSS318-16G-2S+IN brings 10G backbone uplinks to a 16-port access switch at a price point that makes sense for Ugandan ISP distribution layers, hotel networks, and SMB server rooms. When you need to aggregate 16 Gigabit devices and hand off to a 10G fibre core, this switch does it cleanly and reliably.

Key Features

• 16x Gigabit Ethernet ports — wire-speed 1G on every access port, no oversubscription
• 2x 10G SFP+ uplink ports — 10G fibre or DAC uplinks to your core switch or router
• MikroTik SwOS — lightweight, browser-based Layer 2 switch management
• 36 Gbps switching capacity — non-blocking performance across all 18 ports
• 802.1Q VLAN — per-port VLAN tagging for subscriber isolation and network segmentation
• RSTP / STP — loop prevention for redundant uplink topologies
• Port mirroring — traffic capture for network troubleshooting and monitoring
• Bandwidth limiting per port — ingress/egress rate limiting for subscriber management
• Fanless 1U rackmount design — silent, passive-cooled for NOC and server room deployments
• Powered via 24V DC — compatible with MikroTik PoE power supplies and field deployments

Technical Specifications

• Model: CSS318-16G-2S+IN
• Access Ports: 16x Gigabit Ethernet (RJ45)
• Uplink Ports: 2x SFP+ (10G)
• Switching Capacity: 36 Gbps
• Operating System: SwOS (browser-based, no CLI required)
• VLAN: IEEE 802.1Q, port-based and tagged
• Spanning Tree: STP, RSTP
• Port Mirroring: Yes
• Bandwidth Limiting: Per-port ingress and egress
• MAC Address Table: 16K entries
• Power Input: 24V DC (passive PoE in on Port 1) or DC jack
• Max Power Consumption: 12W
• Form Factor: 1U Rackmount
• Dimensions: 443 x 144 x 44 mm
• Operating Temp: -20°C to +60°C
• SKU: MT-CSS318-16G-2S-IN

Ideal Use Cases for Uganda & East Africa ISPs

The CSS318-16G-2S+IN hits the sweet spot between affordability and 10G uplink capability, making it the ideal access-layer switch for a wide range of East African deployments:

• ISP access layer aggregation — connect 16 CPE devices or subscriber ONUs with VLAN isolation per customer, then hand off at 10G to your core
• WISP tower distribution — aggregate multiple sector radios and backhaul links at your tower site with per-port bandwidth control
• Hotel & campus wired networks — provide dedicated Gigabit to each room or office with VLAN segmentation for guest, staff, and management traffic
• SMB server & NAS backbones — connect servers, NAS, hypervisors, and workstations at 1G with a 10G uplink to your core
• NOC infrastructure switching — manage billing servers, NMS platforms, and monitoring tools on isolated VLANs

ISP Billing & Subscriber Management Integration

The CSS318-16G-2S+IN integrates directly into MikroTik-based ISP network architectures. Its per-port VLAN and bandwidth limiting features work seamlessly alongside a RADIUS-based edge router to enforce subscriber policies. Connect your network to our purpose-built ISP billing and subscriber management platform for automated PPPoE session management, bandwidth throttling, invoicing, and real-time reporting:

Explore Our ISP Billing & Subscriber Management System

Built for Ugandan and East African ISPs — with native MikroTik RADIUS integration, PPPoE automation, captive portal, and monthly invoicing included.

Complete Your MikroTik Network Stack

The CSS318-16G-2S+IN is designed to work within a structured MikroTik network architecture. Pair it with these products from NetEdge Supplies Uganda:

• MikroTik CRS310-8G+2S+IN 2.5G/10G Cloud Router Switch — 2.5G aggregation switch with 10G SFP+ uplinks for the distribution layer above this switch
• MikroTik hEX S RB760iGS Gigabit Router with SFP & PoE — edge router for PPPoE termination, RADIUS, and NAT at the ISP gateway
• MikroTik ISP Starter Kit — 4-Device Bundle (Uganda) — complete WISP starter bundle pairing this switch with routers and antennas
• Cisco SG350-10MP 10-Port Gigabit PoE+ Managed Switch — compact PoE managed switch for powering APs, cameras, and VoIP at the edge
• EnGenius Neutron EWS7952FP 48-Port Gigabit PoE+ Managed Switch — high-density PoE access switch for large hotel or campus deployments
• Ruijie Reyee RG-NBS3200 Layer 2 Managed Switch — 24x SFP — fibre-facing distribution switch for upstream aggregation
• Vention Cat6 Patch Cable — RJ45 LAN Network Cable — premium patch cables for every RJ45 port on this switch
• LINK Cat6 UTP Bulk Cable 1000ft Pull Box — structured cabling for permanent runs from this switch to endpoints

What's in the Box

• 1x MikroTik CSS318-16G-2S+IN Managed Switch
• 1x 24V DC Power Adapter
• 1x Rack-mount Kit (ears and screws)
• 1x Quick Setup Guide

Warranty & Local Support

This switch comes with a 12-month MikroTik manufacturer warranty. NetEdge Supplies provides local pre-sales advice, SwOS configuration guidance, VLAN design support, and after-sales troubleshooting across Uganda. Contact our ISP solutions team for a network design consultation.

Frequently Asked Questions

Q: What is the difference between SwOS and RouterOS on this switch?

SwOS is a lightweight browser-based Layer 2 OS for VLAN, RSTP, port mirroring, and bandwidth limiting. It does not support full routing. For PPPoE, RADIUS, and firewall, pair it with the MikroTik hEX S router.

Q: Does it support 10G SFP+ fibre uplinks?

Yes — both SFP+ ports support 10G SMF, MMF, and DAC cables. MikroTik-branded SFP+ modules recommended for full compatibility.

Q: Is it suitable for ISP subscriber distribution?

Yes. Per-port VLAN isolation and bandwidth limiting make it ideal for aggregating subscriber CPE. Pair with the MikroTik ISP Starter Kit and our ISP billing platform for full subscriber automation.

Q: Does it support VLANs?

Yes — IEEE 802.1Q with port-based and tagged VLAN configuration via the SwOS browser interface. Isolate subscriber, guest, staff, and management traffic on separate logical networks.

Q: Is it available in Uganda?

Yes. NetEdge Supplies stocks it at UGX 460,000. Delivery to Kampala, Entebbe, Jinja, Mbarara, and Gulu. Bulk ISP pricing on request.

Q: Can it be powered via PoE?

Yes — Port 1 accepts 24V passive PoE input from a MikroTik PoE router or injector, ideal for tower and field cabinet deployments without a separate DC power run.
