How to Set Up a MikroTik Hotspot with Subscriber Billing in Uganda

Running a WiFi hotspot or internet service business in Uganda without proper subscriber billing is one of the fastest ways to lose revenue. Manual voucher selling, untracked usage, and unpaid subscribers are common pain points for ISPs and hotspot operators across Kampala, Entebbe, Jinja, and upcountry. In this guide, we walk through the complete setup of a MikroTik RouterOS hotspot — from basic captive portal configuration to subscriber billing automation — using genuine MikroTik hardware available at NetEdge Supplies Uganda.

Whether you're deploying at a hotel, campus, apartment block, or running a full ISP operation, this guide covers everything you need to get your MikroTik hotspot generating reliable, trackable revenue. And once your hotspot is live, connect it to Xenfi ISP Billing to automate invoicing, manage subscribers, and control bandwidth — all from one platform.

What Hardware Do You Need?

Before configuring RouterOS, you need the right MikroTik hardware. Here are the recommended options available at NetEdge Supplies Uganda, depending on your deployment scale:

• Small hotspot (café, shop, guesthouse — up to 20 users): MikroTik hAP lite RB941-2nD — affordable RouterOS L4 router with 4 ports and USB modem failover
• Medium hotspot or ISP CPE (20–50 users): MikroTik hAP RouterBOARD with PoE — 5-port 10/100 with PoE in/out, ideal for premises where you also power an outdoor AP
• ISP distribution point (50–200 subscribers): MikroTik RB951Ui-2HnD RouterBOARD — 128MB RAM, USB modem failover, PoE out — the most popular ISP CPE in Uganda
• Core/edge router for multi-CPE ISP networks: MikroTik hEX RB750Gr3 5-Port Gigabit Router — wired-only Gigabit edge router for upstream routing and PPPoE termination

All of the above run RouterOS Level 4 which includes the full Hotspot server. For PoE-powered remote deployments, pair with the MikroTik RBGPOE Gigabit PoE Injector to power the router over Cat6 cable from your distribution point. For the PPPoE configuration that complements hotspot billing, see: How to Set Up PPPoE Subscriber Management on MikroTik with Xenfi Billing in East Africa.

Step 1 — Initial Router Access

Connect your PC to one of the LAN ports of the MikroTik router using a Cat6 Ethernet patch cable. Open Winbox (download free from mikrotik.com) and connect using the router's MAC address — no IP address needed for a fresh device. Default login: username admin, no password. Click OK to log in.

Once inside Winbox, immediately set a strong password via System > Password before proceeding.

Step 2 — Configure the WAN Interface

1. Go to IP > DHCP Client → click Add (+)
2. Set Interface: ether1 → click OK
3. If your ISP provides a static IP, go to IP > Addresses instead and enter your WAN IP, subnet mask, and gateway manually
4. For 4G failover via USB modem (on hAP lite or RB951Ui-2HnD), go to Interfaces > LTE and configure the APN for your Ugandan operator (MTN, Airtel, Lyca)

Step 3 — Create a Local LAN Bridge

1. Go to Bridge > Bridge → click Add (+) → name it bridge-local → click OK
2. Go to Bridge > Ports → add ether2, ether3, ether4 (and ether5 if applicable) and wlan1 to bridge-local
3. Go to IP > Addresses → assign 192.168.88.1/24 to bridge-local

Step 4 — Set Up the WiFi Access Point

1. Go to Wireless > Interfaces → double-click wlan1
2. Set Mode: ap bridge
3. Set Band: 2GHz-b/g/n
4. Set SSID: your hotspot name (e.g., "NetEdge WiFi")
5. Under the Security tab — for a public hotspot, leave security as none
6. Click Enable → OK

Step 5 — Configure IP Pool and DHCP Server

1. Go to IP > Pool → click Add (+) → name: hotspot-pool → Addresses: 192.168.88.10-192.168.88.254 → click OK
2. Go to IP > DHCP Server → click Add (+) → Interface: bridge-local → Address Pool: hotspot-pool → click OK
3. Go to IP > DNS → set Servers: 8.8.8.8 and 8.8.4.4 → tick Allow Remote Requests → click OK

Step 6 — Set Up NAT (Internet Sharing)

1. Go to IP > Firewall > NAT → click Add (+)
2. Chain: srcnat → Out Interface: ether1
3. Action tab → Action: masquerade → click OK

Step 7 — Enable the RouterOS Hotspot Server

1. Go to IP > Hotspot → click Hotspot Setup
2. Hotspot Interface: bridge-local → Next
3. Local address: 192.168.88.1/24 → Next
4. Address Pool: hotspot-pool → Next
5. SSL Certificate: none → Next
6. SMTP Server: leave blank → Next
7. DNS Name: hotspot.local → Next
8. Create a default admin user when prompted → Finish

Step 8 — Create Subscriber Profiles (Bandwidth Plans)

1. Go to IP > Hotspot > User Profiles → click Add (+)
2. Name: e.g., 1Mbps-Daily
3. Rate Limit: 1M/1M
4. Session Timeout: 1d
5. Shared Users: 1
6. Click OK → repeat for other plans (e.g., 2Mbps-Weekly, 5Mbps-Monthly)

Step 9 — Create Hotspot Users (Vouchers)

1. Go to IP > Hotspot > Users → click Add (+)
2. Name: the username (e.g., WIFI2024A)
3. Password: the voucher password
4. Profile: select the bandwidth plan
5. Click OK

Step 10 — Automate Billing with Xenfi ISP Billing

Manual voucher management works for small hotspots but breaks down fast as your subscriber base grows. Xenfi ISP Billing integrates directly with your MikroTik RouterOS installation to:

• Automatically generate and deliver subscriber credentials
• Process monthly and daily billing renewals without manual intervention
• Monitor live bandwidth usage per subscriber
• Suspend and reactivate subscribers automatically on payment status
• Generate invoices and payment records for your business
• Manage multiple MikroTik routers across multiple hotspot sites from one dashboard

Visit Xenfi ISP Billing to transform your hotspot from a manual operation into a scalable, automated internet business.

Recommended Cabling for Your Hotspot Installation

• Vention Cat6 Multi-Colour Patch Cables — colour-code your patch panel connections for clean, organised hotspot rack management
• Cat6 Flat Ethernet Cable (White) — route LAN drops discreetly along walls and under carpets in hotel rooms and offices
• Dutevolns Cat6 Indoor/Outdoor UTP 24AWG — for outdoor-to-indoor ISP drop cables at subscriber premises
